  Home >> DMR radio >> WOUXUN walkie talkie >> WOUXUN KG-UV9K PROPACK - HANDHELD DUAL BAND TRANSCEIVER KIT

WOUXUN KG-UV9K PROPACK - HANDHELD DUAL BAND TRANSCEIVER KIT [Comments(1)|Leave your Comment]
Brand:WOUXUN walkie talkie
Item#:12120401414848
Score:0  (Score change Discount Voucher)
Weight:.85 kg.
List Price:$70.00
Price:$69.00
You Save:$1.00
Qty:

Prev:WOUXUN KG-UV8G AMATEUR RADIO ,2/4M HANDHELD TRANSCEIVER

Next:WOUXUN KG-UV8G - 2/4M HANDHELD TRANSCEIVER PRO PACK

detail

Related

Comment

Payment

Shipping

WOUXUN KG-UV9K PROPACK - HANDHELD DUAL BAND TRANSCEIVER KIT


In stock
SKU
10-904
£89.99
89 Watts










ABOUT WOUXUN KG-UV9K PROPACK - HANDHELD DUAL BAND TRANSCEIVER KIT

Wouxun KG-UV9K PROPACK - Complete Handheld Dual Band Tranceiver Kit.

New version of the ever-popular UV9D - the UV9K! Now with 8.33 step for Airband Channel Spacing Changes.

Included in the Pro Pack:

  • G-UV9K Transceiver with one antenna
  • Two batteries
  • Two belt-clips
  • Software and transfer data Cable
  • Fast charger dock and Power Supply
  • Hand speaker mic
  • Battery eliminator
  • Manual
  • Wrist strap
  • Leather case
  • In-car charger
  • SMA-PL259 adaptor
  • Hands-Free kit

Features:

  • Cross Band Repeater
  • Large Colour Screen
  • Completely turn off display screen background light
  • Completely turn off flickering indicator light
  • Dual Receiving
  • Duplex Work on A and B Areas (TX on one area while RX on the other area simultaneously)
  • RX on the same/different bands of A and B areas simultaneously
  • Simultaneously Scanning on Twin Band, Scanning on Limiting Frequency
  • Channel Groups Scanning
  • Memory Channels 999
  • QT/DQT Encoding/Decoding QT/DQT Scan
  • Non-Standard CTCSS can be set arbitrarily
  • VOX and SOS function
  • Reverse Frequency
  • Amplitude-frequency PTT settings
  • Incoming Message Display Caller ID display
  • DTMF Encoding and Decoding
  • All Calls, Group Calls snd Selective Calls
  • Prior Remote Alarmity Scan Function
  • Wide/Narrow Bandwidth Selection (25KHZ/12.5KHz)
  • Voice Guide: Chinese/English
  • Chinese/English Screen Display
  • English Channel Name Edit
  • Bright Flashlight illumination
  • Single-Tone Pulse Frequency:2100Hz/ 1750Hz/1000Hz/1450Hz
  • Stopwatch
  • Multi Definition for Sidekeys

Technical Specifications:

  • Step: 2.5 / 5.0 / 6.25 / 8.33 / 10 / 12.5 / 25 / 50 / 100 KHz
  • Channel Number: 999
  • Work Mode: F2D/F3E
  • Operating Temperature: -20℃~+40℃
  • Voltage: 7.4 dc
  • Antenna Impedance: 50Ω
  • Weight: 490g
  • Dimensions: 123mm x 58mm x 31mm

Receiver:

  • Adjacent Channel Selectivity: Wide: ≤70dB. Narrow: ≤60dB.
  • Inter Modulation: Wide: ≤65dB. Narrow: ≤60dB.
  • Spurious Response: Wide: ≤70dB. Narrow: ≤70dB.
  • Audio Response: Wide: +1~-3dB(0.3~3KHz). Narrow: +1~-3dB(0.3~3KHz).
  • Signal to Noise Ratio: Wide: ≥45dB. Narrow: ≥40dB.
  • Audio Distortion: ≤5%
  • Audio Power: ≤500mW
  • Sensitivity: 08-136MHz(AM) -106.0dbm SN 13dB. 136-180MHz - 119.0dbm SINAD 13dB. 230-250MHz - 116.0dbm SINAD 13dB. 350-400MHz - 119.0dbm SINAD 13dB. 400-512MHz -119.0dbm SINAD 13dB. 700-986MHz - 96.0dbm SINAD 12dB.

Integration:

  • Suitable for different countries or areas.
  • Frequency Range - 1 TX: 136-174MHZ(FM), 400-512MHZ(FM).
  • Frequency Range - 2 RX: 76-108MHZ(FM), 108-136MHZ (air ground), 136-180MHZ(FM), 230-250MHZ(FM), 350-400MHZ(FM), 400-512MHZ(FM), 700-985MHZ(FM).

Transmitter:

  • Adjacent Channel Selectivity: Wide: ≥70dB. Narrow: ≥60dB
  • Type of Modulation: Wide: 16K F3E. Narrow: 11K F3E
  • Spurious: Wide: ≥60dB. Narrow: ≥60dB
  • Audio Response: Wide: +1~-3dB(0.3~3KHz). Narrow: +1~-3dB(0.3~3KHz).
  • Max Frequency Deviation: Wide: ±5KHz. Narrow: ±2.5KHz
  • Frequency Stability: ±2.5PPM
  • Audio Distortion: ≤5%
  • Output Power: UHF H:5W, M:2W, L:1W. UHF H:5W, M:2W, L:1W.
